CEDES : The GridScan/Mini is an extremely compact SIL 2-certified safety light curtain. Its door blanking function allows it to be integrated into the door design. The system with an FSS output fulfills EN 13849-1 Cat. 2 without testing.
Price:
• Criss-cross beams
• SIL 2 certified (TÜV approved)
• FSS version fulfills SIL 2 without testing
• Direct integration into the door edge (SB and DB types)
• Door speeds up to 1.6 m/s
• Waterproof housing (IP67) and very high light reserve make the GridScan/Mini
insensitive to dust, dirt and water
• Electrical synchronization for increased light and strobe immunity
• Short-circuit proof semiconductor output PNP/NPN (push-pull) or FSS output
• Cross section only 12 mm × 16 mm
Mechanical |
|
|---|---|
| Cross section : | 12 mm × 16 mm |
Electrical |
|
|---|---|
| Supply voltage USP : | 10 ... 30 VDC |
Others |
|
|---|---|
| Certificates : | CE, TÜV |
| Safety category : | EN ISO 13849-1:2015, Cat. 2, PL d EN 61508:2010, SIL 2 EN 12978:2003, +A1:2009 EN 12453:2017 E device |
• Automatic door recognition using TOF technology
• Offers double safeguarding when combined with light curtain
• Extremely reliable object detection using TOF technology
• No need to configure the monitored area
• Ideal for modernization and new facilities efficient Prevents accidents
• Prevents damage to elevator
doors
• Entrance area monitoring reduces door- opening tim
• Excellent detection capability, independent of reflectance
• Individual setting of the detection area
• Detection area operates with all types of background
• Insensitive to ambient ligh
• TÜV – EC Type examination certified
• SIL 2 certified
• Direct integration into the door edge due to door blanking
• Combined output with PNP/NPN (push-pull) and FSS
• Changeable operation between blanking and static mode
• Easiest alignment
• 2nd output for additional information
• Ideal for modernization projects due to FSS control unit
• Door closing speed up to 1.6 m/s
• Fulfills SIL 2 without testing if FSS output selected
• Low energy consumption
• Ideal for both static and dynamic applications
• Integrated controller with LED status indicator
• Short-circuit-proof semiconductor-output PNP/NPN (push-pull)
• Requires no grounding (earth)
• Selectable monitoring height of either 1,582 mm or 1,822 mm
• IP65 (Standard) and IP67 (waterproof) versions available
• ATEX-version available
• Edge can be front or side mounted
