Siko: Electronic display / Measurement display MA504/1. Quasi-absolute, small mains-independent LCD display


Linear Measurement

Price:

• Display accuracy max. 10 μm
• Repeat accuracy max. ±0.01 mm
• Lowest-power LCD
• Metric or decimal-inch indication
• Incremental measurement and reset function
• Direct reference/offset value input
• Battery-buffered memory
• Battery operation
• MS500H sensor pluggable

  • Categories: Linear Measurement
  • Tags:
Download
Mechanical
MATERIAL PROPERTIES : built-in housing, plastic
temperature range : 0 … 60 °C
Protection category : IP40
Electrical
Operating voltage : 3VDC
Current consumption : ~150 µA
Others

Industries

Datasheet_MA504
