Unitronics affordable All-in-One smart PLC with a textual HMI and keyboard, plus onboard I/O configurations
| Item | Summary |
| M91-2-R1 | 10 Digital, 1 Analog Inputs, 6 Relay Outputs |
| M91-2-R2C | 10 Digital, 2 Analog Inputs, 6 Relay Outputs |
| M91-2-R6C | 6 Digital, 6 Analog Inputs, 6 Relay Outputs |
| M91-2-R34 | 20 Digital, 2 D/A1 Inputs, 12 Relay Outputs |
| M91-2-T1 | 12 Digital Inputs, 12 Transistor Outputs |
| M91-2-T38 | 22 Digital Inputs, 16 Transistor Outputs |
| M91-2-T2C | 10 Digital, 2 D/A 1 Inputs, 12 Transistor Outputs |
| M91-2-UN2 | 10 Digital, 2 D/A/ , PT100/TC 1 Inputs, 12 Transistor Outputs |
| M91-2-UA2 | 10 Digital, 2 D/A/TC 1 Inputs, 10 Transistor, 2 Analog Outputs |
| M91-2-RA22 | 8 Digital, 2 D/A, 2 PT100/TC/Digital1 Inputs, 8 Relay, 2 Analog Outputs |
Price:
• For simple PLC control with text-only HMI + keypad M91
• Full-functional programmable controllers (PLCs)
• Onboard I/Os with expands up to 150 I/Os.
• A built-in textual HMI panel
• Specifically designed to control small machines
• Simple-to-medium automation tasks
• Compact, economical–low-budget control without compromising on features
Mechanical |
|
|---|---|
| HMI : | 2 Line textual display, Multi language |
| Operating Temperature: | 0 … 50 °C |
| Cut-out : | 92x92 mm (3.622”x3.622”) |
| Graphic Display: | STN, LCD. Backlight Yellow-green |
| Keypad: | 15 Keys |
Electrical |
|
|---|---|
| IO Options : | digital, analog, temperature and high speed, expand upto 150 I/Os |
| Communication : | Built in 1 RS232/485, CANbus( C model only) |
| Protocol : | MODBUS protocol, FB Protocol, CANBus( C models only) |
| Program Memory : | 36K |
| Supply Voltage : | 24VDC |
Others |
|---|
• Different Unistream Communication modules for each controller series – Modular/Build in /PLC
• Greatly expands communication with add-on ports
• Unistream with Industry 4.0 via features such as MQTT, VNC, FTP, Web Server, email and text messaging, and SQL Client
• Plug & play communications for CANopen, CAN Layer2, MODBUS, EtherNet/IP, and more
• Virtual HMI- the PLC stores and runs the program logic & HMI user application within the PLC itself
• Access your process remotely via any mobile phone, PC, or remote display
• Expand up to 2048 I/O
• Available in 3 models B3/5/10.
• 12.1″ color touchscreen from the front
• Snap-in I/O modules for an All-in-One controller
• Expands up to 1000 I/Os
• Multi-language display
• Built-in Alarm Screen
• Vision 430-Fully functional Programmable Logic •
• 4.3″ color touch screen
• Includes an onboard I/O configurations
• Expands up to 512 I/Os
