Unitronics Vision series advanced programmable logic controller from the back—big & high resolution color touch screen


V1210

Price:

• 12.1″ color touchscreen from the front
• Snap-in I/O modules for an All-in-One controller
• Expands up to 1000 I/Os
• Multi-language display
• Built-in Alarm Screen

  • Categories: V1210
  • Tags: and waste water management automotive energy and environment food processing Packaging Petrochemicals plastic and textile
Download
Mechanical
HMI : 12.1" color touchscreen, Multi-Language
Operating Temperature: 0 … 50 °C
Cut-out : 297x228.5mm (11.69"x8.9”)
Graphic Display : TFT, LCD display
Keypad : Virtual
Electrical
IO Options : digital, analog, high speed, temperature, and weight measurement, expand upto 1000 I/Os
Communication : Built in 1 Mini USB for Programming, 1 CANbus, 2 Isolated RS232/485, Add on 1 serial /Ethernet
Protocol : ModbusTCP, CANOpen, BackNet, FB Protocol, SNMP V1, KNX
Program Memory : 2MB
Supply Voltage : 12/24 VDC
Others
General Features : • Web server • E-mail & SMS • 4G Modem support • Remote access utilities

Industries

and waste water management
automotive
energy and environment
food processing
Packaging
Petrochemicals
plastic and textile

DataSheet_V1040-T20B
